Two-stage 25 micron + 1 micron SANIC filtration
20" BIG filter cartridges
Antimicrobial SANIC polypropylene cartridges
Reduces sand, rust, dirt, silt, scale, and suspended solids
High-flow whole-house filtration
High-output UV-C disinfection
Chemical-free microbiological treatment
Stainless-steel UV reactor
Digital controller with lamp-life countdown
UV lamp replacement alarm
IP54-rated controller
Lockable, weather-resistant protective frame
Pre-plumbed plug-and-play design
Reversible mounting
1" inlet and outlet connections
-
Whole-house water filtration and UV disinfection
Rainwater harvesting and treatment
Bore and well water
Rural and off-grid water supplies
Domestic water treatment
Commercial water filtration
Sediment pre-filtration before UV
Protection of pumps, valves, plumbing, and downstream equipment
-
System Type: Two-stage sediment filtration + UV disinfection
Filter Size: 20" BIG
First Stage: 25 micron SANIC sediment cartridge
Second Stage: 1 micron SANIC sediment cartridge
UV System: High-output UV-C
UV Reactor: Stainless steel
UV Dose: 30–40 mJ/cm²
Connections: 1" BSP
Maximum Operating Pressure: 8.3 bar (830 kPa)
Temperature Range: 4°C to 45°C
Power Supply: 110–240 V AC, 50/60 Hz
Controller: Digital with lamp-life countdown and alarm
Controller Protection: IP54
Installation: Pre-plumbed plug-and-play
-
Typical Replacement Interval: Approximately every 6 months for sediment cartridges, depending on water quality, sediment levels, and water usage.
25 Micron SANIC Cartridge: Replace when clogged, heavily discoloured, or when water flow decreases.
1 Micron SANIC Cartridge: Replace when flow decreases or pressure loss becomes excessive.
UV Lamp: Replace approximately every 12 months, according to the specified lamp life.
Quartz Sleeve: Inspect and clean at least quarterly. Replace if cracked, damaged, or heavily scaled.
Quartz Sleeve O-Ring: Inspect annually and replace if damaged or deteriorated.
Maintenance Kit: Available for routine servicing.
Best Used With
Coarse sediment pre-filter for high-sediment water.
Activated carbon filtration for chlorine, taste, and odour reduction.
Iron and manganese treatment where required.
Additional pre-treatment where hardness or UV transmittance is outside recommended limits.
Not Suitable For
Dissolved salt or TDS reduction.
Water softening or hardness reduction.
Chlorine, taste, or odour reduction without carbon filtration.
Dissolved chemical contaminant removal.
Significant iron or manganese removal without suitable pre-treatment.
Heavy sediment loads without suitable pre-filtration.
