Hydra TRIO 20" Big 90 Micron Clear hydra/Clear Cartridge
Hydra Big Trio Self-Cleaning Filter – 20” Big
The Hydra Big Trio is a high-flow, three-stage filtration system designed for applications where higher water flow and greater sediment capacity are required.
It combines a self-cleaning pre-filter with two empty 20” Big standard filter housings, giving you the flexibility to select cartridges that suit your water quality and treatment requirements.
The Hydra Big is particularly well suited to high-flow applications where maintaining good flow with minimal pressure drop is important, especially where higher levels of sediment are present.
The system uses materials selected for suitability with drinking water applications, including a reinforced polypropylene head and drain components, PET filter bowls and silicone seals.
Flow rates will depend on the cartridges selected and the operating conditions of the system.
Self-Cleaning Pre-Filter
The built-in Hydra self-cleaning filter removes larger sediment before the water reaches the cartridge filters. Its counter-current cleaning system uses reverse water flow to flush accumulated dirt from the mesh, reducing the need to remove and manually clean the filter.
Cleaning is quick and simple and can be carried out manually, with automatic cleaning also available for even lower maintenance.
The included pressure gauges provide an easy way to monitor pressure across the system and identify when cleaning or filter replacement may be required.
Features
High-flow 90-micron stainless steel self-cleaning mesh filter
Two 20” Big standard filter housings for additional filtration
Designed for high-flow applications with low pressure drop
Suitable for higher sediment loads
Counter-current self-cleaning system
Manual or automatic cleaning options
Drinking-water-suitable materials
Reinforced polypropylene filter head and drain components
Durable PET filter bowls
Silicone O-ring seals
Pressure gauges with 0–12 bar (0–170 psi) range
Helps extend the life of downstream filters, valves and water treatment equipment
Long service life of up to 5 years for the Hydra pre-filter, depending on water quality and use
Working Conditions
Specification Rating Pressure Gauge Range 0–12 bar (0–170 psi)
Build Your Own High-Flow Filtration System
The Hydra Big Trio gives you the flexibility to build a high-capacity filtration system around your specific water requirements.
The self-cleaning pre-filter handles coarse sediment before the water reaches the two 20” Big cartridge housings. Simply select the cartridges that best suit your application — whether you need finer sediment filtration, carbon filtration or other specialist treatment.
The larger 20” Big housings provide greater cartridge capacity and are designed to deliver higher flow rates while helping minimise pressure loss.
Choose the two cartridges that suit your needs from our range.
